St Francis 46

Order Hull#01 for Sep launch
US$1,200,000.00 (Approx £946,051)
  • Boat REF#  ·  314040
  • Length  ·  13.98m
  • Year  ·  New
  • Construction  ·  Composite
  • Underwater profile  ·  Multihull
  • Sleeping berths  ·  8
  • Engine  ·  2 x diesel 45hp, 2 X Yanmar 4JH45-CR 45HP with SD60 Sail Drives
  • Lying  ·  Eastern Cape
Boatshed New Build Boats
Boatshed New Build Boats
Bruce Stirk

Meet the Builder

St Francis catamarans

St Francis 46

Want to hear from the builders of the St Francis boats? See our exclusive interview with them now.

Special Offers: Hull #01 available at discounted price for launch in September 2023.

Lifestyle & Use

The St Francis 46 has been designed as a live aboard for blue water cruising that can be sailed shorthanded on long passages in comfort and safety. It is available in 3 cabin owners version or 4 cabin version. The large sliding door and window between the galley/saloon and cockpit area allows them to be combined into a large, covered entertainment area.

Unique Features

The ergonomics of the St Francis have been refined over the years. No sharp corners to the furniture, hand holds and railings have been strategically placed, giving you easy safe passage, whether below or on deck. The extra-large windows in the saloon and galley give excellent all-round vision.

Design & Build

This ultra-modern fast cruising catamaran is the result of design collaboration between Anton Du Toit of Du Toit Yacht Design and Angelo Lavranos. With a greater loading capacity, it is possible to support better on-board systems such as air conditioning, improved refrigeration, state of the art navigation and communications systems.

Prices & Process

The price for the St Francis 46 starts at US$1200000.00. A full range of popular extra items are available allowing you to build a boat to your exacting requirements. The experienced team will work with you to put together the bespoke package that is just right for you. Pricing of the vessel will be amended to reflect the final build specification agreed to between the boatyard & purchaser. OFFER - 5% DISCOUNT ON HULL #1.

Extra Details

Designer Anton du Toit, Angelo Lavranos
Builder St. Francis Marine
Lying Eastern Cape
Fuel capacity 700.0 ltr (154.0 USG) Total - 2 Tanks
Water capacity 800.0 ltr (176.0 USG) Total - 2 Tanks
Holding tank capacity 176.0 ltr (38.7 USG) Total - 2 Tanks

Mechanical

Engine 2 x diesel 45hp
Engine make and model 2 X Yanmar 4JH45-CR 45HP with SD60 Sail Drives
Engine Hours Not Recorded
Engine Cooled Indirect
Steering wheel
Drive saildrive
Prop(s) 2 X 3 Blade fixed Propellers
Fuel consumption (approx) Not Recorded
Engine spares

2 x Vetus raw water filters
2 x Yanmar B-25 instrument Panels
2 x Vetus Exhaust systems
2 x Exhaust Anti-siphon valves
2 x Rule Engine compartment extraction blowers.
2 x Fireboy - Xintex #MA0450NVC Manual / Auto Gas Filled automatic fire extinguishers with heat & smoke detectors as well as audible & visible alarms.
2 x LED Lights in each engine compartment.
2x 1100gph rule electric bilge pumps with float switches and manual override switch connected to audible and visual alarms at helm.
Kohler Genset 6EKOD 6 kW 110V @ 60Hz.
Balanced spade rudders reinforced to take drying out/storage.
Anodised aluminium tiller arms
Matching ertalyte rudder bearings (inner size 72mm) (outer size to 95mm bottom
Stainless steel emergency tiller arm with stainless steel access hatch, removable winch handle.
Lecomble and Schmidt hydraulic steering system.
Destroyer type 32" 5 spoke stainless steel leather covered steering wheel.
1 hydraulic bulkhead mount steering smart pump with 2 x Lecomble and Schmidt rams.
Seastar engine controls - seastar SL3 dual control and cables.
GRP engine beds
Battery cables and connection
Black sondor sound seal black (fire retardant, non absorbant CE approved)
2 x Carbon monoxide monitors
2 x 3 blade fixed propellers 20" x 16" for saildrive diesel motors only.

Dimensions

Length 13.98m
LWL 13.87m
Beam 8.00m
Draft Min 1.24m
Airdraft 21.10m

Rig

Sloop rigged Sparcraft Aluminium spars with Stainless Steel standing rigging

Sails

Reefing mainsail North Sails - SlabStack Pack, Fully Battened, Lazy Jacks, 3 Reefs
Headsail North Sails - Furling
Other sails Storm Jib

Mainsail - North Sails Pinhead Tour Xi Norlam Xi11/09. 3 x Reefs 6 x Battens.
Fully battened with lazy jacks & stackpack (logo on stackpack).
Furling Genoa - North Sails Tour Xi Norlam Xi09. Rope Luff Pad & Roller Reef structure, UV Protection Leech and foot.
Jib - North Sails Polyester High Visibility 10oz Storm Orange.
Genaker system
Mast halyard marlow double braid 12mm x 46m
12mm sheets x 2 marlow double braid 12mm x 22m
5 x halyards: main, genoa, baby stay, topping lift, code zero
1 x 8mm genoa furling line
1 x 8mm code zero furling continuous line
Sparcraft single spreader standard aluminium anodised mast boom, forward cross beam and compression post with walkway.
Profurl C350 Genoa furler
Boom vang support
Capshroud chainplate
Harken Battcar system "C"
LED spreader lights
LED navigation lights
Shakespeare UFO TV Antenna
Radar bracket
2 x 1.8m tracks with stop ends
2 x Genoa cars
2 x Lewmar genoa jammers 12 - 14mm
1 x Lewmar roller furler jammer 8 - 10mm
2 x 57mm ESP foot blocks
1 x 57mm ESP single block
Main sheet system:
1 x traveller track 32mm
Traveller car 4 tons.
Traveller controls and tackle
1 x Lewmar double traveller jammer 10 - 12mm
Mainsheet Harken 5 x 75mm single ESP blocks
4 x 75mm single ESP upstands
2 x Lewmar mainsheet jammers 12 - 14mm

Electrical Systems

12 volt battery, 110 volt generator, 110 / 240 shore power voltage, 5 batteries charged by: engine, solar panels, shore power, generator

Construction

Construction Composite
Underwater profile Multihull
Finish Paint finish

New reverse Wave Cutter Bow profile.
Vinyl ester (Epoxy based resin) infused Core cell foam sandwich.
E-glass stitched quadriaxial non-crimp fabric throughout construction.
All strong points Carbon Fibre reinforced.
4 Coats Osmosis Protection Epoxy Primer.
2 Coats Awlgrip Epoxy coatings Spray system (Matterhorn White).
2 coats Awlgrip epoxy coatings spray system (Navy blue) waterline stripe
Four blocks of pine with attached rope to protect rub rails when lifting.
Deck:
All deck hatches low profile
Vacuum bagged and hand laid-up foam core, quadriaxial non crimp fabric.
2 coats Awlgrip epoxy coatings spray system (Matterhorn white)
Spray on Awlgrip non-skid deck paint
All strong points carbon fibre reinforced
GRP squared cockpit seats
Hardtop bimini with rear support frame.
Rain catchment system.
Space to accommodate solar panels.
4 forward windows
2 x size 60 hatches port and starboard in bimini.
Roof to view sails and for additional ventilation.
Spray on Awlgrip non skid deck paint on cockpit floor.
Inspection covers on top of each fuel tank
2 x stainless steel deck fillers.
2 x Racor 500MAM fuel and water filters
Fuel tank interlink to equalise tanks
WEMA tank monitor system for 8 generic user inputs (2 diesel, 2 water, 2 holding tanks and 2 spare)
Signwriting professional boat name - owner to supply artwork

Accommodation

Total # of berths 8
No. of double berths 4
Cabin(s) 4
Sink 4
Shower 4
Heads 4 heads (Electric)

SALOON
Large, raised seating / dining area with a fixed table that can accommodate 8 people.
Force 10, 3 Burner Ceramic top electric hob and 30L oven available in 120V or 240V.
1 x 160L Isotherm S/ Steel double drawer freezer in Port Side Companionway.
1 x 190L Isotherm S/ Steel double drawer fridge.
Large sink with Pull-out mixer tap alongside drying cupboard with electric fan.
Trash hole with cover integrated in galley top for ease of cleaning.
Large sliding window in galley for access between Galley & Cockpit dining area.
Saloon settee vinyl owner to select colour
All flooring Belgotex vinyl owner to select colour
Maple with satin finish
All furniture construction in foam sandwich and bonded to hulls
Corian tops colour white Onyx
Saloon and galley ceiling panels vinyl covered
Cabin headboards vinyl
Cabin seats vinyl
Dashboard panels vinyl
Cabin window surrounds vinyl
Nav station carbon look vinyl

Accommodation

Broiler
Oven
Sink
Refrigerator
Freezer
Manual water system
Pressurised water system
Hot water system
Fresh water wash
Raw water wash
Cockpit shower

SALOON
Large, raised seating / dining area with a fixed table that can accommodate 8 people.
Force 10, 3 Burner Ceramic top electric hob and 30L oven available in 120V or 240V.
1 x 160L Isotherm S/ Steel double drawer freezer in Port Side Companionway.
1 x 190L Isotherm S/ Steel double drawer fridge.
Large sink with Pull-out mixer tap alongside drying cupboard with electric fan.
Trash hole with cover integrated in galley top for ease of cleaning.
Large sliding window in galley for access between Galley & Cockpit dining area.
Saloon settee vinyl owner to select colour
All flooring Belgotex vinyl owner to select colour
Maple with satin finish
All furniture construction in foam sandwich and bonded to hulls
Corian tops colour white Onyx
Saloon and galley ceiling panels vinyl covered
Cabin headboards vinyl
Cabin seats vinyl
Dashboard panels vinyl
Cabin window surrounds vinyl
Nav station carbon look vinyl

Deck Gear

Sail cover
Cockpit cover
Fenders
Swim Platform
Swim Ladder
Instrument Covers
Bimini

1 halyard winches
2 sheet winches
Electric 1 x Maxwell HRC10-10 Electric Anchor Windlass. windlass
2 anchors
(Main Rocna and secondary Fortress )
100.00m of chain
2 X 50 ST 2 speed (Manual Aluminium Self Tailing) Primary Winches.
1 x 46 ST (Manual Aluminium Self Tailing) main traveller &
roller furling Winch.
1 x 46 ST (Manual Aluminium Self Tailing) halyard & boom extension Winch at mast.
3 x 10" lock in handles.
1 x 33kg Rocna galvanised anchor 100m x 10mm test chain.
1 x 9kg FX 37 - Secondary Fortress anchor, 10m x 8mm
chain & 30m X 16mm Mooring warp.
Para anchoring & Anchor Bridle mounting points on crossbeam.
Maxwell AA560 Chain Counter at helm.
Anchor Bridle & Chain Swivel connector.
6 x cylindrical fenders and fender lines

Nav Equipment

Compass
Speed
Log
Wind
VHF DSC radio
GPS
Chart plotter
Autopilot
Navigation lights
Depth sounder

B&G V60 -B: VHF DSC radio fixed mount with integrated AIS transmitter and receiver, wireless handset support.
B&G H60 wireless handset for V60F radio
B&G Zeus S-12 chartplotter steering station
B&G NAC-3 autopilot core pack, high current NC3 autopilot computer, Precision 9 compass and RF-25 rudder feedback unit
B&G Triton autopilot controller and 4.1" display pack
B&G WS 310 wind sensor
EC1-100 universal engine and control interface

Safety Equipment

Fume detector
Carbon Monoxide detector
Liferaft
Life jackets
Life buoys
Danbuoy
Safety harnesses
Horn
EPIRB 406MHz
Emergency steering

8 bilge pumps (2 manual / 6 electric)

2 x Whale Manual Bilge Pumps.
4 x1100 gph Rule Auto Electric bilge pumps with float switches and alarms.
2 x Fireboy - Xintex #MA0450NVC Manual / Auto Gas Filled automatic fire extinguishers with heat & smoke detectors as well as audible & visible alarms at helm.
2 x 1100 gph Rule Electric Bilge Pumps with float switches and manual override switch, connected to audible & visual alarms at helm.
8 x Life jackets orange 150N
2 x Lifebuoy complete yellow
4 x Handheld distress flares red
4 x Rocket flares red
2 x Floating smoke markers orange
Waterproof torch
Flag N
Flag Q
Flag V
Flag C
Life raft Viking 8 man
2 x Black ball shapes 400mm
EPIRB ACR 406M
3 x Fire extinguishers handheld 1.5kg
Capsize bottle - waterproof
2 x Space blankets
Bosuns chair
4 x Safety harnesses adult
Telescopic boathook
Portable bilge pump
Signal mirror
Copy of collisions regulations
Nautical almanac
Sportlight rechargeable 12V
Sheet ID
Signal card
Galvanised bucket 2L
Heaving line 8mm x 30mm
Light M4
Floating light LED torpedo
Anchor drogue
Radar reflector tubular 50mm
Plastic bucket 5L
Toolkit
First aid kit solas LFA 2
Bolt cutter
Knife
1 set wooden bungs for seacocks
4 x pad eyes and jacklines
SAS category C safety survey after launch

Where the particulars herein give details of a boat, whether new or used, they are intended to give a fair description of the vessel but are not guaranteed as accurate or complete. They shall not form part of any offer or contract for the sale of the vessel. The prospective purchaser is recommended to independently check the particulars and the vessel. The vendor is not selling in the course of a business unless otherwise stated. Personal property is excluded from the sale of the vessel unless specifically included in the listing specification above or in a purchase contract. Personal property may be equipment or gear not permanently attached to the vessel including but not limited to: artwork, entertainment equipment, fishing equipment, TV receivers, recreational equipment, kayaks, tools, and personal appliances. Photos that may incidentally depict owners' personal property do not convey that such items are included in the sale of the vessel unless such items are specifically listed herein. At all times, where the particulars herein give details of a new boat and/or a new boat to be supplied/built by a builder/manufacturer, or a boat to be chartered, via our introduction, we do not guarantee or assume responsibility for the accuracy or reliability of any information offered by third-party companies in respect thereof including without limitation new boat builders/manufacturers, charter companies and/or companies/businesses which are ‘Friends of Boatshed’. We shall not be responsible for, or party to, any transactions, contracts or agreements between you and such third-party providers of products or services and it is incumbent upon you to verify such details direct with such entities and contract with them at your sole discretion and on terms that you agree.
